Model | I.T.A, FEM II, III, IV |
Capacity | 1.0t to 40t |
Service weight | 30kg to 1500kg |
Surface | Paint coating |
Certification | CE, ISO, TUV |
Packing | 300-500pcs per 20’ container |
Application | Used for forklift |
Feature:
| Metric Market | ||
| Item No. | Cross Section | Capacity x Load Center |
| Width x Thickess(mm) | kg x mm | |
| 1 | 80x40 | 1000x500 |
| 2 | 100x30 | 750x500 |
| 3 | 100x35 | 1000x500 |
| 4 | 100x40 | 1250x500 |
| 5 | 100x45 | 1500x500 |
| 6 | 100x50 | 1650x500 |
| 7 | 120x35 | 1000x500 |
| 8 | 120x40 | 1500x500 |
| 9 | 120x45 | 1500x500 |
| 10 | 120x50 | 2450x500 |
| 11 | 125x40 | 1500x500 |
| 12 | 125x45 | 2000x500 |
| 13 | 125x50 | 2500x500 |
| 14 | 130x40 | 1500x500 |
| 15 | 130x45 | 2000x500 |
| 16 | 130x60 | 3000x500 |
| 17 | 140x50 | 2700x500 |
| 18 | 150x50 | 2500x600 |
| 19 | 150x60 | 3500x600 |
| 20 | 150x65 | 4000x600 |
| 21 | 150x70 | 4500x600 |
| 22 | 150x75 | 5000x600 |
| Inch Market | |||
| Item No. | Cross Section | Cross Section | Capacity x Load Center |
| Width x Thickess(inch) | Width x Thickess(mm) | kg x mm | |
| 1 | 1 1/2 x 3 | 80x40 | 850x600 |
| 2 | 1 3/8 x 4 | 100x35 | 850x600 |
| 3 | 1 1/2 x 4 | 100x40 | 1150x600 |
| 4 | 1 3/4 x 4 | 100x45 | 1400x600 |
| 5 | 2 x 4 | 100x50 | 1750x600 |
| 6 | 1 1/2 x5 | 125x40 | 1400x600 |
| 7 | 1 3/4 x 5 | 125x45 | 1750x600 |
| 8 | 2 x 5 | 125x50 | 2150x600 |
| 9 | 2 x 6 | 150x50 | 2600x600 |
| 10 | 2 1/4 x 6 | 150x60 | 3750x600 |
| 11 | 2 1/2 x 6 | 150x65 | 4400x600 |
| 12 | 2 3/4 x 6 | 150x70 | 5100x600 |
| 13 | 3 x 6 | 150x75 | 5850x600 |
| 14 | 2 3/4 x 8 | 200x70 | 4530x900 |
| 15 | 3 1/2 x 8 | 200x90 | 7500x900 |
| 16 | 4 x 10 | 250x100 | 8675x1200 |
| 17 | 4 x 12 | 300x100 | 10425x1200 |
| 18 | 5 x 12 | 300x125 | 13575x1200 |
| 19 | 6 x 12 | 300x150 | 23425x1200 |
