Type | Manual Brake Winch |
Work Load | 1800lbs |
Max. Capacity | 12KN |
Gear Ratio | 5.0/1 |
Brake Winch With Wire Rope |
|
Surface treatment | Powder coated |
Color | yellow |
Cable Size | 5.0mmx10m |
Net Weight | 8.1KG |
Apply to:
Box trailer, Flat trailer,Construction trailers, Lives stock trailer, Agriculture vehicle, Industry vehicle, Building vehicle, Road trailer, Commercial trailer,etc.
Feature:
1.large drum hub to maximize cable life.
2.self-activating automatic brake hold the load securely when crank handle is released
3.With cable or strap.
4.safety guard cover available
5.Top quality with competitive price.
6.Widely used in the double beam bridge crane and gantry crane
7.Easy to install and high quality.
8.Compact structure and reasonable design.
Top Grade Gears Assy for 1500kgs loading.
Thrust Bearing 51204,φ40x14mm
Lashing Buckle breaking capacity 5000KG fittd with strap 50MM width 51MM
