Tube Type | Φ57mm |
Wind | Top wind handle |
Load Capacity | 2000lbs |
Length of Extension | 15” |
Retracted total length | 20.25” |
Locking pin & Chains | Ø 9/16" |
Unit Weight | 14lbs |
Brand | DNL |
Finishing | outer body powder coated, Inner body zinc plated. |
Packing | 160pcs per plywood case (120x92x113cm) |
Apply to:
Box trailer, Horse trailer, Flat trailer,Caravan,Construction trailers, Lives stock trailer, Agriculture vehicle, Industry vehicle, Building vehicle, Road trailer, Commercial trailer,etc.
Feature:
Foldable handle saves more space when retracting with ingenious structure, firm and no noise.
Ergonomic knob offers the best experience of operating easily, no feeling of tiredness.
Reliable quality and stable performance of spindle & bearing extend the service life of products.
80mm Square tube with top handle 1200kg static load screw stroke 300mm Parking Jacks
70mm Square tube with top handle 1000kg static load screw stroke 310mm Parking Jacks
5000lbs Tubular swivel round jack side wind 10" travel
48mm Jockey Wheel, Hot-Dip-Galvanized, rubber wheel
