| ITEM NO. | WEIGHT (kg) | WLL (T) | B.L (T) | E±1 | A±0.5 | H±1 | W±1 | L±2 |
| 6-8 | 0.25 | 1.12 | 4.48 | 8 | 8 | 17.7 | 21.5 | 77.3 |
| 7/8-8 | 0.32 | 2 | 8 | 10.5 | 9.5 | 18.5 | 33.5 | 89 |
| 10-8 | 0.73 | 3.15 | 12.6 | 13 | 12.5 | 29 | 46 | 126 |
| 13-8 | 1.6 | 5.3 | 21.2 | 16.5 | 15 | 42.7 | 57.5 | 163.5 |
| 16-8 | 2.8 | 8 | 32 | 19 | 18.5 | 45.4 | 74 | 183.5 |
| 20-8 | 5 | 12.5 | 50 | 24 | 23 | 56 | 74 | 219 |
| 22-8 | 6.3 | 15 | 60 | 27 | 27 | 68.5 | 90 | 254 |
| 26-8 | 14.5 | 21.2 | 84.8 | 30 | 30 | 77 | 102 | 309 |
1.Super alloy steel.
2.Quenched and Tempered.
3.Suitable for G80 EN818-2 chains.
4.100% Magnetic powder inspection.
5.Individually proof load test at 2.5 times WLL.
6.Fatigue test at 1.5 times WLL for 20,000 cycles.
7.Strict breaking test.
8.Surface treatment: Powder coated.
Drum moving and lifting.
Time and labor saving.
Super carbon steel.
High tensile strength.
Super alloy steel.
Quenched and tempered.
To suit G80 chains.
Ergonomic design.
Special rough terrain truck.
