Tube Type | Φ57mm |
Wind | Side wind handle |
Load Capacity | 2000lbs |
Length of Extension | 10” |
Retracted total length | 17.5” |
Locking pin & Chains | Ø 9/16" |
Unit Weight | 12lbs |
Brand | DNL |
Finishing | outer body powder coated, Inner body zinc plated. |
Packing | 130pcs per plywood case (120x92x113cm) |
Apply to:
Box trailer, Horse trailer, Flat trailer,Caravan,Construction trailers, Lives stock trailer, Agriculture vehicle, Industry vehicle, Building vehicle, Road trailer, Commercial trailer,etc.
Feature:
Ergonomic knob offers the best experience of operating easily, no feeling of tiredness.
High quality gears make your operation more smoothly and safely.
Reliable quality and stable performance of spindle & bearing extend the service life of products.
Support Leg, Tubular welding bracket, 240mm extended height with handle
Support Leg, Tubular welding bracket, 240mm extended height
7000lbs Direct weld square jack side wind 13" drop leg 15" travel
70mm Square tube with top handle 1000kg static load screw stroke 430mm parking jacks
