Feature：

• Dynamic Pull Test

The equipment can set a specific pull force value. While the winch is driven by the motor for reciprocating motion, the pull force remains constant, simulating real-world conditions where the winch continuously bears load during repeated operation.

• Static Pull Test

The system allows users to set and maintain a fixed pull force value via the touchscreen interface, enabling the winch to sustain a constant load without rotation.

• Torque Test

The system measures and displays the required torque value for winch rotation under load via the touchscreen. Users can set a torque threshold on the interface, triggering an alarm when the actual torque exceeds the preset value.

• Automatic Mode

The system allows users to set the test cycles and test distance via the touchscreen, enabling the winch to perform dynamic tests automatically. The system will stop automatically once the preset number of cycles is completed.

• Manual Mode

The system allows operators to manually control winch functions—such as load application and rotation—through tactile touchscreen commands.

• Real-time Curve Monitoring

During testing, the system continuously records and graphically displays real-time data—including pull force, torque values, and cycle counts—as dynamic curves for immediate performance analysis.

• Data Processing

The system allows test data recorded during winch testing to be exported via USB drive to a computer for further analysis. The data can be formatted into tables or analytical charts for comprehensive evaluation.

Equipment Parameters：
